起订:1件
供应:10件
发货:3天内
主要用途：
本机主要用于连续方泡海绵（50米）的无限长切片工作，占地面积小，操作方便，生产效率高，是连续发泡生产厂家的必须配套设备（本机可选配自动收料装置，效率更高）。本机可以选配钢支架固定式平台，能够有效的增加海绵与平台间的摩擦力，大力改良切割的质量，提高海绵的利用率。
This machine is mostly used for 50m foam blocks long sheet slicing. it is small footprint . the operation is simple and the production efficiency is high, it is the necessary equipment for continuously foaming produced (this machine chooses the automatic-accept equipment, the production efficiency is higher). This machine can choose the fixed steel platform, which can increase the friction between foam and the platform , improve cutting effect so the utilization ratio of sponge is enhanced.
主要技术参数(Main Technical Specification):
型号(Model) | GHLG-1650 | GHLG-2150 |
可切泡绵宽度（Cutting foam width) | W1650mm | W2150mm |
可切泡绵高度（Cutting foam height) | H1250mm | H1250mm |
行走速度(Treading speed) | 2~90m/min | 0~69 m/min |
刀带长度(Blade length) | L7400mm | L8400mm |
总功率(Total power) | 8.92kw | 10.42kw |
机器重量(Machine weight) | 1500kg | 1800kg |
机器外形尺寸（长×宽×高） (Machine external size) | L3550×W2640×H2350mm | L4050×W2640×H2350mm |
注：以上数据和参数仅供参考，实际技术数据以出厂产品为准。
